Flat Plate Lifting Sockets consist of steel tube with inner thread which is welded to a flat steel plate.
Flat Plate Lifting Sockets are available in two materials.
Flat Plate Lifting Sockets are designed and manufactured in accordance with EU Machinery Directive 2006/42/EC and VDI/BV-BS 6205. The plate insert anchors meet the requirements for safe lifting and handling of concrete elements.
Surface treatment insert: Electro galvanised or A4 stainless steel Material electro galvanised: S355J2 according to EN 10025 Material A4/A2 stainless steel : 1.4401/1.4301 according to EN 10088
